Outdoor Antenna Quadplexer (F) ALCAD MM-407

Shipment in 0days
Cost from 4.00€
  • Outdoor Antenna Quadplexer (F) ALCAD MM-407

Click on the photo to enlarge it

Outdoor Antenna Quadplexer (F) ALCAD MM-407
FULL DESCRIPTION
MM-407 multiplexer is used as a device that adds up signals from multiple antennas, installed on a mast, and is placed there, near the antenna set. It has BI/FM input, designed for connecting radio FM antenna, BIII input to connect an antenna for VHF band, and two UHF inputs. It is possible preamplifier's feeding. The diplexer has 5 F-type connectors, and is closed in metal, screening casing.
Installation and security notice for diplexer's/multiplexer's users
The MM-407 multiplexer is designed for mast installation and can work in open spaces. To avoid any possible damage, the device should not be powered until all the connections are properly made. Optional preamplifier's feeding through UHF2 input must not exceed 60 mA.
Specifications
 Name MM-407
 Number of inputs   4
 Frequency range Band BI/ FM | BIII | UHF1 | UHF2
  MHz 40-108 | 160-260 | 470-862 | 470-862
 Insertion loss dB 0.9 +/-0.4|0.9 +/-0.4|4.7 +/-0.8|4.7 +/-0.8
 Isolation between inputs dB  >=20
 Rejection between inputs dB  >=30
 Return loss dB  >=10
 DC cross mA - | 60
 Working temperature ºC -10 .. +55
 Weather protection standard   IP 53
